linear, equal-percentage or invers-equal percentage(with cams)

up to 4-fold possible (up to dw=0.2 bar / 3 psig)

Zero and Span
Gain and Damping
Valve Action
Bypass switch

independently adjustable

independently adjustable

direct or reverse adjustable

connects input w directly with output y

Air Supply

1.4 to 6 bar (20 to 90 psig)

Stroke range

 8 to 200 mm (0.3 to 8.0 in)

Angle of Rotation

30 to 180 degree angle

Protection Class

 IP54, optional IP 65

Electrical Classification
Base Unit     ATEX
Accessories   ATEX
             FM and CSA

For use on ships or vessels

Constructive safety II 2 G EEx c IIC T6

“intrinsic safety” II 2 G EEx ia IIC T6

“Intrinsic safety” Class I, Div. 1, Groups A, B, C, D

Lloyd’s registered

Pneumatic Connection

 G1/8

Electrical Connection (f. Accessories) M20 x 1.5 or 1/2-14 NPT (others with Adapter AD...)

Ambient Temperature

-40 to +80 °C (-40 to +176°F)

Humidity

 up to 100 %

Weight

0.7 kg / 1.5 lbs (double acting: 0.9 kg / 2.0 lbs)

Optional Features

Inductive Limit Switches (2- or 3-wire)

Micro Switches

Electrical Position Transmitter (4 to 20 mA)

Manifold with staggered connection

Gauges

Pneumatic Volume Boosters

Attachment to linear actuators

acc. to IEC 534 part 6 (NAMUR)

rotary actuators

acc. to VDI/VDE 3845

any other linear or rotary actuator by means of extensive attachment kit offering
