Display

5 inch,
800 × 480 pixels,
108 × 65 mm (W x H),
> 200 cd/m2

Size (W x H x D)

175 × 111 × 50 mm (W × H × D)

Weight

850 g with battery

Protection class

IP 67

Operating temperature

0 – 55 °C

Battery

Li-Ion, rechargeable, 6 hours operation time

Power adapter I charger

100 – 240 V AC, 50/60 Hz

Probe connector

Dual Lemo-00 (T/R)

PC interface

Micro USB

Memory card

SD-Card 16 GB max

Reporting

Test report and A-Scan screen shot on SD-Card, Video recording of A-Scan

Pulser

120 – 300 V, 30 – 500 ns, flank < 10 ns, Spike, Square wave option

Puls Repetition Frequency

15 – 2000 Hz

Damping

50 and 1000 Ohm

Receiver

110 dB dynamic, 0.51 ~ 19.6 MHz analog bandwidth

Filter

BB 1-5 MHz, 2,25 MHz, 4 MHz, 5 MHz, 10 MHz, 13 MHz, 15 MHz

Gates

A and B independent, B triggered by A, C option

Units

mm, inch, μs

Options

AWS sizing tool (AWS D1.1),DAC 16 points according to EN 1712, EN 1713, EN 1714, ASTM E164, TCG 110 dBdynamic, DGS sizing tool according to EN 1712, EN 1713, EN 1714, ASTM E164,Data Logger, 3rd gate C, Square Wave Pulser

Compliance

EN 55011,EN 61000-6-2: 2011, EN 12668, ASTM E 1324, E317, ANSI/NCSL Z540-1-1994, MIL-STD 45662A, MIL-STD 2154
