ABNOX計量閥4192902技術參數
Technical Data | |
Dosing range [cm3] | 1.00 - 6.00 |
Input medium specification | Lubricants up to NLGI 3 / max. 1'000'000 mPa.s |
Min. / max. workingpressure medium inlet [bar] | 20/200 |
Connection medium inlet internal thread | 1/4'' BSP |
Connection medium inlet external thread | 1/4'' BSP |
Connection medium outlet internal thread | 1/8'' BSP |
Compressed air quality | ISO 8573-1:2020 [6:4:4] |
Optimum pneumatic operatingpressure [bar] | 6 |
Min. pneumatic operatingpressure [bar] | 5 |
Max. pneumatic operatingpressure [bar] | 7 |
Pneumatic connection internal thread | M3 for hose ?4/2 mm |
Fastening thread | M4 |
Weight [kg] | 1.2 |
ABNOX計量閥4192902產品介紹
通過新的 ABNOX 閥 AXDV-C4（帶有水平手柄），能夠?qū)崿F(xiàn)潤滑劑的均勻和清潔的應用，從而獲得終極的過程可靠性。它允許準確地將微量的復雜潤滑劑放置在設備上。高重復性的精確和清潔應用意味著能夠長期節省潤滑劑！
Ultimate process reliability at uniformly and clean application of lubricants – made possible by the new ABNOX Valve AXDV-C4 with handgrip horizontal. It allows accurate placing of minute quantities of your complex lubricant on your device. Precise and clean application at high repeatability means permanent saving of your expensive lubricant!
ABNOX計量閥AXDV-C系列其他常用型號：
ABNOX AXDV-C1 4191802
ABNOX AXDV-C2 4192302
ABNOX AXDV-C3 4192802
ABNOX AXDV-C4 4192902
ABNOX Volumetric Metering Valve NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于ABNOX計量閥4192902的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for ABNOX products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:www.jjxdch.cn.
