Part number

8242402

Power consumption

P=3W

PROFIBUS protocol options

P ROFIBUS-DP and DP-V1 to IEC 61158

Automatic baud rate detection

9.6 kbaud .. 12 Mbaud

Connection technology

Via 9-pin sub D plug
Pin asignment to IEC 61158

Bus terminatlon

Not integrated, implement using suitable PROFIBUS plug with terminat-ing resistors that can be switched on.

Station address

0..125, can be set using DIP switch

Name of the GSD file

SEW_ _6003.GSD (PROFIBUS-DP)

SEWA6003.GSD (PROFIBUS-DP-V1)

DP identity number

6003hex = 24579dec

Appllcation-specific parameter-setting data (Set-Prm application data)

Length: 9 bytes
Hex parameter settings 00,00,00,06,81,00,00,01,01 = DP diagnostics alam= OFF
Hex parameter settings 00,00,00,06,81,00,00,01 ,00 = DP diagnostics alam = ON

DP configurations for DDLM_ Chk_ Cfg

F0hex= 1 process data word (1 I/O word)
F1hex = 2 process data words (2 I/O words)
F2hex = 3 process data words (3 /0 words)
0hex, F5hex = 6 process data words (6 /0 words)
0hex, F9hex = 10 process data words (10 I/O words)
F3hex, FOhex = parameter channel + 1 process data word (5 IO words)
F3hex, F1hex = parameter channel + 2 process data words (6 /O words)
F3hex, F2hex = parameter channel + 3 process data words (7 I/O words)
F3hex, F5hex = parameter channel + 6 process data words (10 /O words)
F3hex, F9hex = parameter channel +10 process data words (14 Vo words)

Diagnostics data

Max. 8 bytes

Standard dlagnostics: 6 bytes

Tools for startup

MOVITOOLS@ PC program

DBG11B keypad
