TIME DELAY

Adjustment

3 digit   push-button switch

Range

50 ms to 999   minutes in 5 ranges

Repeatability

±0.1%, ±.02   seconds over specified timing range

ACCURACIES

Delay On Make

±1% of set time,   plus fixed error of 80 ms max. (40 ms typical including power-on response   time)

Interval, One   shot

±1% of set time,   plus fixed error of 35 ms max. (10 ms typical)

Delay On Break

±1% of set time,   plus fixed error of 75 ms max. (10 ms typical)

Repeat Cycle, On   Time

±1% of set time,   plus fixed error of 35 ms max. (10 ms typical)

Repeat Cycle,   Off Time

±1% of set time,   minus error of 65 ms max. (10 ms typical)

INPUT

Operating   Voltage

24, 120 VAC, 12,   24, 48 VDC ±10% (DC models have reverse polarity protection. Unfiltered input   voltage to them must be full wave rectified)

Power On   Response

.05 sec. max.

Power Off Reset   Time

.15 sec. min.

Start Switch   Closure Time

.020 sec. to   initiate timing cycle; .050 sec. to reset delay during timing cycle

Power   Consumption

2 VA max.

Frequency

50/60 Hz

OUTPUT

Type

Relay DPDT (2   form C)

Rating

10 A max.   resistive at 240 VAC; 100 mA at 5 VDC min. load current

Life

Mechanical:   10,000,000 operations
  Full Load: 500,000 operations

TIMING LIGHT   LOGIC

Repeat Cycle

Flashing during   ON time; Full On during OFF time

Other Logic   Modes

Flashing during   timing; continuously on after time out

PROTECTION

Transient   Voltage

12, 24, 48 V   timers are protected by an 8.8 joule metal oxide varistor; 120 V timers are   protected by a 30 joule metal oxide varistor

Dielectric   Breakdown

1500 VAC, RMS   min. at 60 Hz between input and outputs and between outputs

MECHANICAL

Termination

11-pin plug

Mounting

Socket mount,   part number MSO-0011P-012

ENVIRONMENTAL

Storage   Temperature

-23°C to 70°C

Operating   Temperature

-23°C to 55°C

Humidity

95% relative

TIMING

Selectable Time   Ranges

.05 to 9.99   seconds; .1 to 99.9 seconds; 1 to 999 seconds; .1 to 99.9 minutes; 1 to 999   minutes (times less than 50 ms are not recommended due to the response time   of the mechanical relay)

Selectable   Operating Logic Modes

Repeat Cycle   (50% fixed duty cycle)
  Single Shot (1 shot)
  Delay On Break (D.O.B.)
  Interval (Intervl)
  Delay On Make (D.O.M.)

PROGRAMMING

To program the   timer, remove voltage from the unit and select the operating logic mode and   the time range; use the digital switches to select the required time (0 to   999)
